Water Soaking Sterilizer (1-5 T/H) | for Dairy Products, Beverages, Jelly
Place of Origin: |
China |
Brand Name: |
Weishu |
Model Number: |
WS-BS |
Capacity: |
1–5 tons |
Raw materials: |
SUS304/SUS316L |
Application products |
Dairy products, beverages, jelly |
Certification: |
CE |
Minimum Order Quantity: |
1 |
Packaging Details: |
Wooden case |
Delivery Time: |
30days |
Payment Terms: |
TT/LC |
- Description
- Working Principle
- Application
- Specifications
- Recommended Products
Description
The Continuous Water Soaking Sterilizer is designed for efficient thermal processing of packaged foods and beverages. It is capable of handling a production capacity of 1–5 tons per hour and achieves sterilizing temperatures up to 98°C, which can be customized according to order requirements. The machine features a steam-heated water tank with automatic control via a steam solenoid valve, ensuring optimal heat utilization. With fully adjustable processing and cooling times, along with a variable-speed conveyor belt, it offers flexibility for various production needs. The equipment is robustly constructed, operationally stable, and designed for user-friendly operation.
Working Principle
This sterilizer operates by immersing products in a temperature-controlled hot water tank heated by steam. The steam flow is precisely regulated by a solenoid valve to maintain the required sterilizing temperature. Products are conveyed through the heated water bath for a set duration (10–35 minutes, adjustable via belt speed) to achieve thorough sterilization. Subsequently, they pass through a cooling section where they are cooled to approximately 20°C, also with adjustable immersion time. The entire process ensures uniform heat treatment and efficient energy use, with the hot water being recirculated to minimize waste.
Application
Widely used in the production of dairy products, beverages, jelly,etc.
Specifications
|
Produce cappacity |
1-5T/H |
| Sterilizing temperature | < 98 ℃ It can be ste to order |
| Sterilizing time | 10-35 minute speed infinitive adjusting |
| Cooling temperature | 20 ℃ |
| Cooling time | 10-25 minute speed infinitive adjusting |
| Steam pressure | 0.4 Mpa |
| Link bekt time | 0.17 -10m/min speed infinitive adjusting |
| Centrifuge blower fan | 3 kw |
| Compete weight | About 6000kg |
| Outline dimension | 1600x2600x 2000 mm |
